Customization: Available
After-sales Service: One Year Not Include The Quick-Wear Parts
Warranty: One Year Not Include The Quick-Wear Parts
Send Inquiry

Product Description

Basic Specifications
Model NO.
GOPZ202
Application
Workshop, Warehouse, Building
Lift Mechanism
Lift Chain
Carrying Capacity
300kg
Moves
Self-propelled
Driven Type
DC Battery
Certification
CE, ISO 9001
HS Code
84281090
Product Description

300KGS Load Capacity - Electric Aerial Order Picker

This electric order picker is specifically designed for high-efficiency operations in warehouses, workshops, supermarket aisles, stations, and other narrow space environments. It provides a stable and safe platform for overhead picking and maintenance tasks.

  • ✓
    Narrow Space Access: With an overall width of only 0.7m, it navigates easily through tight aisles.
  • ✓
    High Efficiency: Self-propelled movement allows for rapid relocation without descending.
  • ✓
    Safety Guaranteed: Equipped with emergency stop buttons, low voltage alarms, and overload protection.
Technical Parameters
SPECIFICATION GOPZ202 GOPZ302 GOPZ3.502
Machine Specifications
Working Height4m5m5.5m
Platform Floor Height2m3m3.5m
S.W.L (Load Capacity)300KG300KG300KG
Weight400KG574KG588KG
Overall Size (LxW)1.53m x 0.7m1.53m x 0.7m1.53m x 0.7m
Drive Speed (Stowed)4Km/h4Km/h4Km/h
Electrical Specifications
Batteries2 x 12V / 120Ah
Integrated Charger24V / 15A
Drive Motors2 x 24V / 0.5KW
Lifting Motor24VDC / 1.5KW
Standard Equipment
● Proportional controls
● Low voltage alarm
● Can Bus Technology
● Battery charge indicator
● Emergency down button
● Overloading limited
● Charger protection
● Emergency stop button
Product Display
300kgs Warehouse Picking up Electric Aerial Order Picker
Frequently Asked Questions
What is the maximum load capacity of the electric order picker?
The standard safe working load (S.W.L) for all mentioned models is 300kg.
What is the difference between working height and platform height?
The platform floor height is the actual height of the platform from the ground (2m to 3.5m), while the working height includes the reach of an average operator (4m to 5.5m).
Can this machine be used in narrow warehouse aisles?
Yes, it features a compact design with an overall width of only 0.7m (700mm), making it ideal for narrow spaces.
What power source does the order picker use?
It is powered by a 24V DC system using two 12V/120Ah batteries and comes with an integrated 24V/15A charger.
What safety features are included as standard?
Standard safety features include proportional controls, emergency stop buttons, emergency descent systems, low voltage alarms, and overload limiters.
Is the machine self-propelled?
Yes, it is a self-propelled unit with drive speeds up to 4km/h when stowed and 1.1km/h when raised.
